How to create Test Suite & Test Case in SoapUI

thumbnail

Understanding the SOAP Protocol

Before we create a SOAPUI Test case, let us understand basics about the SOAP Protocol. This will help you use SOAP UI to test SOAP requests and response effectively.

SOAP stands for Simple Object Access Protocol. Below are the properties of a SOAP Protocol.

  • It is an XML-based protocol for communicating between two different systems.
  • It is a platform and language independent. Hence, a system developed using Java can communicate with a system developed in.NET.
  • SOAP requests/response are transported via HTTP.

In this SoapUI Test Suite tutorial, you will learn:

Learn the SOAP Message FORMAT

A SOAP message is an ordinary XML document containing the following elements. Message can be either a request message or a response message.

SOAP Message FORMAT

After setting up the workspace which we had performed in the last tutorial, we have to create SoapUI project structure, test suites, test cases in order to test a given web service. Let us understand a SoapUI Project example to create a new SOAP project.

Creating a SOAP Project

Step 1) Now, depending upon the project, we need to import SOAP/REST protocol. We will create a new SOAP Project.

Creating a new SOAP Project

Step 2) We will make use following SOAP request http://www.dneonline.com/calculator.asmx?wsdl

  1. Enter the Project Name
  2. Enter the path of the WSDL request. In this case http://www.dneonline.com/calculator.asmx?wsdl
  3. Click OK
How to Create a new SOAP Project

Note:

  • Create sample request for all operations? It creates a sample request for all the available operations in the given WSDL. As soon as you enter the WSDL address, this option is checked automatically. You may uncheck it.
  • Create, a Test Suite for the imported WSDL: Creates a SoapUI test suite within the project for the imported WSDL.
  • Relative Paths: It enables the user to save all the files relative to the project file.

Step 3) Upon creating the SOAP project with the above-said WSDL, we will be able to see that there are two operations that will be imported into the project.

How to Create a new SOAP Project

Step 4)

Expand the first request and right-click on the ‘Add.’ Then click on ‘New Request’.

Steps to Create a new SOAP Project

Then Click on ‘OK’. It will display the SOAP request in the XML format

Steps for Creating a new SOAP Project
  1. Enter the ‘intA’ and ‘intB’
  2. Click on the submit button
  3. Response XML will be displayed right side pane.
How to Create a new SOAP Project

You may wonder why create Test Cases? When you can directly test Webservice here…

Well, you can send a request for one operation. What about others? How many combinations of inputs for Additions can you do using this operation? You have to edit the request for each and every combination.

For example: If you want to add from 4 and 4 instead of 5 and 5… You need to edit the operation again. So, one has to create a test suite/cases to have all possible scenarios tested without having to directly edit the operation itself.

How to Create Test Suite in SoapUI

Below are the steps to create Test Suite in SoapUI:

Step 1) Right-click on the root of the project

Within the project, testers can create a test suite by performing a right-click on the root of the project.

How to Create Test Suite in SoapUI

Step 2) Enter the Test suite details

We need to enter the name of the test suite and press OK.

Steps to Create Test Suite in SoapUI

Step 3) Verify the created Test suite

The created test suite is displayed the navigator pane as shown below.

Steps for Creating Test Suite in SoapUI

Step 4) Open the Test suite

The test Suite window opens in the Right Pane. As we have just created there are NO SoapUI test cases. Hence all options are disabled.

Creating Test Suite in SoapUI

How to Create Test Case in SoapUI

Here is a step by step process for creating a test case in SoapUI:

Step 1) Within a test suite, we can create multiple tests by performing right click on the ‘test suite’ and choosing ‘New TestCase’.

How to Create Test Case in SoapUI

Step 2) Specify the name of the Test Case and click ‘OK’.

Creating Test Case in SoapUI

Step 3) The created test case has zero steps as shown below.

Steps to Create Test Case in SoapUI

Note: We can see that the test case is added with zero test steps for all kinds of tests available. Upon adding the test steps, the numbers in the bracket would change automatically.

The functional test step should go into ‘Test Steps’ while a performance test step should go into ‘Load Test’ and a security test step should go into ‘security Tests’.

Step 4) We can insert a variety of test steps by performing a right-click on test steps and selecting an appropriate test step as shown below. So, if you were to test a REST Webservice, you would select the REST Test Request.

Steps for Creating Test Case in SoapUI

Adding a Test Step in SoapUI

Now let us add a test step to validate the imported SOAP testing request:

Step 1) Add a new step ‘SOAP Request’ as shown below.

Adding a Test Step in SoapUI

Step 2) Enter the step name and click OK.

Adding a new Test Step in SoapUI

Step 3) Upon clicking ‘OK’, a dialog pops up to select the operation to invoke. All the operations are listed, and user can select the operation that they would like to invoke.

  • There are many operations that will be listed. The Operations are the same except the SOAP version used.CalculatorSoap – uses SOAP version 1.1 whereas,CalculatorSoap12 – uses SOAP version 1.2
  • The Version does not matter for us in this context. Hence you can select the one of your choice.How to Add a Test Step in SoapUI
  • Upon Selecting the operation, click ‘Ok’Adding a Test Step in SoapUI

Step 4) While adding a test case, we can add standard assertions. Assertions also called as checkpoints/validation points which we will be dealing in detail in the next tutorial.

We can add following checkpoints/assertions while creating test case. Let us create a test case with the option which means creating test step WITHOUT any of the below validation points

Steps for Adding a Test Step in SoapUI
  1. Verifies if the response message is SOAP, upon executing the test.
  2. Verifies if the response schema is valid.
  3. Verifies if the SOAP response contains FAULT.

Step 5) Upon creating the test case, the request XML is shown below. The structure of the XML is explained within the below snapshot.

Steps to Add a Test Step in SoapUI

Step 6) The test step count is now incremented to one as we have just added one test step. Similarly, upon adding load and security tests step, the corresponding number would be automatically incremented based on the number of steps added.

Steps to Add a Test Step in SoapUI

Sending Request Manually & Reading Response in SoapUI

Step 1) We would like to add two Integer Number.

  • intA – 5
  • intB – 5

Next,

  1. We need to enter these inputs in place of the question mark which will be sent as request XML.
  2. After inputting those values into the corresponding XML tags, click ‘submit request’ button to check the response.
Sending Request Manually in SoapUI

Step 2) Upon submitting a request the web service request is processed by the webserver and sends back a response as shown below.

By reading the response, we are able to conclude 5 plus 5 is 10.

Reading Response in SoapUI

Understanding the Soap Response & Log Panels

As explained at the beginning of this SoapUI testing tutorial, the SOAP messages are transported via HTTP protocol. Let us take a look at the RAW messages. This will help us learn how the SOAP request and response were transported by HTTP.

Step 1) Click ‘RAW’ Tab in both SOAP-UI request Window.

  1. The Request is posted to the webserver. Hence, the POST method of Http is used.
  2. The SOAP Request is transported in the body of the Http message.
Understanding the Soap Response

Step 2) Now click ‘RAW’ Tab in SOAP-UI Response Window to understand how the response is sent via HTTP.

  1. After processing the request, the Http response code (200) is shown which means it is a success. The webserver has processed it successfully.
  2. The SOAP response is sent back to the client as part of the body of the HTTP message.
Understanding the Soap Response

A Quick snapshot of the Http Response codes for easy understanding and debugging. The below table will help you to trouble shoot based on the HTTP code received from the webserver.

Http CodeDescription
1xx:Informational – This means a request received and continuing process.
2xx:Success – The action was successfully received, understood, and accepted.
3xx:Redirection – This means further action must be taken in order to complete the request.
4xx:Client Error – This means the request contains bad syntax or cannot be fulfilled
5xx:Server Error – The server failed to fulfil an apparently valid request

Step 3) Let us understand the other information that are displayed in the test case window.

Understand the Soap Response
  1. Represent NO header in the request that is being sent
  2. Represents NO attachments in the request that is being sent to the web server.
  3. Represents 10 header information and the same are displayed upon clicking on it.
  4. Represents that there are no attachments from the response message.

LOGS PANE:

Logs pane has complete information regarding the transaction between the client and the server. Users will be able to see the tabs of the Log pane as shown below. We will discuss the most commonly used log panes when working with SOAP-UI.

Logs Pane in SoapUI

SoapUI Log – Displays the response information from the webserver. The same information is stored in soapui.log file of the SOAP-UI installed folder under ‘bin’ directory.

SoapUI Log

Http Log – Displays all the HTTP packet transfer. All the information in ‘RAW’ is shown in HTTP log.

Http Log in SoapUI

Error Log – Error log displays all the errors that we have encountered during the entire project session. The same information is available in ‘soapui-errors.log’ present in the ‘bin’ directory of the SOAP UI installed location.

Memory Log – This tab monitors the memory consumption and displays it in the form of the chart as shown below. It is really helpful when there is a memory intensive operation is performed.

Memory Log in SoapUI

Now that we have created a test suite, test case, test step, and got a response, next step is to validate the response. We will deal with types of assertions in the next tutorial.
