TFX on Cloud AI Platform Pipelines

Install

It then checks which version of TFX is installed, does an import, and sets and prints the Project ID:

The Getting Started Notebook starts by installing TFX and Kubeflow Pipelines (KFP) into the VM which Jupyter Lab is running in.

Connect with your Google Cloud services

The pipeline configuration needs your project ID, which you can get through the notebook and set as an environmental variable.

# Read GCP project id from env.
shell_output=!gcloud config list --format 'value(core.project)' 2>/dev/null
GCP_PROJECT_ID=shell_output[0]
print("GCP project ID:" + GCP_PROJECT_ID)

Now set your KFP cluster endpoint.

This can be found from the URL of the Pipelines dashboard. Go to the Kubeflow Pipeline dashboard and look at the URL. The endpoint is everything in the URL starting with the https://, up to, and including, googleusercontent.com.

ENDPOINT='' # Enter YOUR ENDPOINT here.

The notebook then sets a unique name for the custom Docker image:

# Docker image name for the pipeline image
CUSTOM_TFX_IMAGE='gcr.io/' + GCP_PROJECT_ID + '/tfx-pipeline'

6. Copy a template into your project directory

Edit the next notebook cell to set a name for your pipeline. In this tutorial we will use my_pipeline.

PIPELINE_NAME="my_pipeline"
PROJECT_DIR=os.path.join(os.path.expanduser("~"),"imported",PIPELINE_NAME)

The notebook then uses the tfx CLI to copy the pipeline template. This tutorial uses the Chicago Taxi dataset to perform binary classification, so the template sets the model to taxi:

!tfx template copy \
  --pipeline-name={PIPELINE_NAME} \
  --destination-path={PROJECT_DIR} \
  --model=taxi

The notebook then changes its CWD context to the project directory:

%cd {PROJECT_DIR}

Browse the pipeline files

On the left-hand side of the Cloud AI Platform Notebook, you should see a file browser. There should be a directory with your pipeline name (my_pipeline). Open it and view the files. (You’ll be able to open them and edit from the notebook environment as well.)

# You can also list the files from the shell
 ls

The tfx template copy command above created a basic scaffold of files that build a pipeline. These include Python source codes, sample data, and Jupyter notebooks. These are meant for this particular example. For your own pipelines these would be the supporting files that your pipeline requires.

Here is brief description of the Python files.

• pipeline – This directory contains the definition of the pipeline
  • configs.py — defines common constants for pipeline runners
  • pipeline.py — defines TFX components and a pipeline
• models – This directory contains ML model definitions.
  • features.py features_test.py — defines features for the model
  • preprocessing.py / preprocessing_test.py — defines preprocessing jobs using tf::Transform
  • estimator – This directory contains an Estimator based model.
    • constants.py — defines constants of the model
    • model.py / model_test.py — defines DNN model using TF estimator
  • keras – This directory contains a Keras based model.
    • constants.py — defines constants of the model
    • model.py / model_test.py — defines DNN model using Keras
• beam_runner.py / kubeflow_runner.py — define runners for each orchestration engine

7. Run your first TFX pipeline on Kubeflow

The notebook will run the pipeline using the tfx run CLI command.

Connect to storage

Running pipelines create artifacts which have to be stored in ML-Metadata. Artifacts refer to payloads, which are files that must be stored in a file system or block storage. For this tutorial, we’ll use GCS to store our metadata payloads, using the bucket that was created automatically during setup. Its name will be <your-project-id>-kubeflowpipelines-default.

Create the pipeline

The notebook will upload our sample data to GCS bucket so that we can use it in our pipeline later.

gsutil cp data/data.csv gs://{GOOGLE_CLOUD_PROJECT}-kubeflowpipelines-default/tfx-template/data/taxi/data.csv

The notebook then uses the tfx pipeline create command to create the pipeline.

!tfx pipeline create  \
--pipeline-path=kubeflow_runner.py \
--endpoint={ENDPOINT} \
--build-image

While creating a pipeline, Dockerfile will be generated to build a Docker image. Don’t forget to add these files to your source control system (for example, git) along with other source files.

Run the pipeline

The notebook then uses the tfx run create command to start an execution run of your pipeline. You will also see this run listed under Experiments in the Kubeflow Pipelines Dashboard.

tfx run create --pipeline-name={PIPELINE_NAME} --endpoint={ENDPOINT}

You can view your pipeline from the Kubeflow Pipelines Dashboard.Note: If your pipeline run fails, you can see detailed logs in the KFP Dashboard. One of the major sources of failure is permission related problems. Make sure your KFP cluster has permissions to access Google Cloud APIs. This can be configured when you create a KFP cluster in GCP, or see Troubleshooting document in GCP.

8. Validate your data

The first task in any data science or ML project is to understand and clean the data.

• Understand the data types for each feature
• Look for anomalies and missing values
• Understand the distributions for each feature

Components

• ExampleGen ingests and splits the input dataset.
• StatisticsGen calculates statistics for the dataset.
• SchemaGen SchemaGen examines the statistics and creates a data schema.
• ExampleValidator looks for anomalies and missing values in the dataset.

In Jupyter lab file editor:

In pipeline/pipeline.py, uncomment the lines which append these components to your pipeline:

# components.append(statistics_gen)
# components.append(schema_gen)
# components.append(example_validator)

(ExampleGen was already enabled when the template files were copied.)

Update the pipeline and re-run it

# Update the pipeline
! tfx pipeline update \
  --pipeline-path=kubeflow_runner.py \
  --endpoint={ENDPOINT}

! tfx run create --pipeline-name "{PIPELINE_NAME}"

Check the pipeline

For Kubeflow Orchestrator, visit KFP dashboard and find pipeline outputs in the page for your pipeline run. Click “Experiments” tab on the left, and “All runs” in the Experiments page. You should be able to find the run with the name of your pipeline.

More advanced example

The example presented here is really only meant to get you started. For a more advanced example see the TensorFlow Data Validation Colab.

For more information on using TFDV to explore and validate a dataset, see the examples on tensorflow.org.

9. Feature engineering

You can increase the predictive quality of your data and/or reduce dimensionality with feature engineering.

• Feature crosses
• Vocabularies
• Embeddings
• PCA
• Categorical encoding

One of the benefits of using TFX is that you will write your transformation code once, and the resulting transforms will be consistent between training and serving.

Components

• Transform performs feature engineering on the dataset.

In Jupyter lab file editor:

In pipeline/pipeline.py, find and uncomment the line which appends Transform to the pipeline.

# components.append(transform)

Update the pipeline and re-run it

# Update the pipeline
! tfx pipeline update \
  --pipeline-path=kubeflow_runner.py \
  --endpoint={ENDPOINT}

! tfx run create --pipeline-name "{PIPELINE_NAME}"

Check pipeline outputs

For Kubeflow Orchestrator, visit KFP dashboard and find pipeline outputs in the page for your pipeline run. Click “Experiments” tab on the left, and “All runs” in the Experiments page. You should be able to find the run with the name of your pipeline.

More advanced example

The example presented here is really only meant to get you started. For a more advanced example see the TensorFlow Transform Colab.

10. Training

Train a TensorFlow model with your nice, clean, transformed data.

• Include the transformations from the previous step so that they are applied consistently
• Save the results as a SavedModel for production
• Visualize and explore the training process using TensorBoard
• Also save an EvalSavedModel for analysis of model performance

Components

• Trainer trains a TensorFlow model.

In Jupyter lab file editor:

In pipeline/pipeline.py, find and uncomment the which appends Trainer to the pipeline:

# components.append(trainer)

Update the pipeline and re-run it

# Update the pipeline
! tfx pipeline update \
  --pipeline-path=kubeflow_runner.py \
  --endpoint={ENDPOINT}

! tfx run create --pipeline-name "{PIPELINE_NAME}"

Check pipeline outputs

For Kubeflow Orchestrator, visit KFP dashboard and find pipeline outputs in the page for your pipeline run. Click “Experiments” tab on the left, and “All runs” in the Experiments page. You should be able to find the run with the name of your pipeline.

More advanced example

The example presented here is really only meant to get you started. For a more advanced example see the TensorBoard Tutorial.

11. Analyzing model performance

Understanding more than just the top level metrics.

• Users experience model performance for their queries only
• Poor performance on slices of data can be hidden by top level metrics
• Model fairness is important
• Often key subsets of users or data are very important, and may be small
  • Performance in critical but unusual conditions
  • Performance for key audiences such as influencers
• If you’re replacing a model that is currently in production, first make sure that the new one is better

Components

• Evaluator performs deep analysis of the training results.

In Jupyter lab file editor:

In pipeline/pipeline.py, find and uncomment the line which appends Evaluator to the pipeline:

components.append(evaluator)

Update the pipeline and re-run it

# Update the pipeline
! tfx pipeline update \
  --pipeline-path=kubeflow_runner.py \
  --endpoint={ENDPOINT}

! tfx run create --pipeline-name "{PIPELINE_NAME}"

Check pipeline outputs

For Kubeflow Orchestrator, visit KFP dashboard and find pipeline outputs in the page for your pipeline run. Click “Experiments” tab on the left, and “All runs” in the Experiments page. You should be able to find the run with the name of your pipeline.

12. Serving the model

If the new model is ready, make it so.

• Pusher deploys SavedModels to well-known locations

Deployment targets receive new models from well-known locations

• TensorFlow Serving
• TensorFlow Lite
• TensorFlow JS
• TensorFlow Hub

Components

• Pusher deploys the model to a serving infrastructure.

In Jupyter lab file editor:

In pipeline/pipeline.py, find and uncomment the line that appends Pusher to the pipeline:

# components.append(pusher)

Check pipeline outputs

For Kubeflow Orchestrator, visit KFP dashboard and find pipeline outputs in the page for your pipeline run. Click “Experiments” tab on the left, and “All runs” in the Experiments page. You should be able to find the run with the name of your pipeline.

Available deployment targets

You have now trained and validated your model, and your model is now ready for production. You can now deploy your model to any of the TensorFlow deployment targets, including:

• TensorFlow Serving, for serving your model on a server or server farm and processing REST and/or gRPC inference requests.
• TensorFlow Lite, for including your model in an Android or iOS native mobile application, or in a Raspberry Pi, IoT, or microcontroller application.
• TensorFlow.js, for running your model in a web browser or Node.JS application.

More advanced examples

The example presented above is really only meant to get you started. Below are some examples of integration with other Cloud services.

Kubeflow Pipelines resource considerations

Depending on the requirements of your workload, the default configuration for your Kubeflow Pipelines deployment may or may not meet your needs. You can customize your resource configurations using pipeline_operator_funcs in your call to KubeflowDagRunnerConfig.

pipeline_operator_funcs is a list of OpFunc items, which transforms all the generated ContainerOp instances in the KFP pipeline spec which is compiled from KubeflowDagRunner.

For example, to configure memory we can use set_memory_request to declare the amount of memory needed. A typical way to do that is to create a wrapper for set_memory_request and use it to add to to the list of pipeline OpFuncs:

def request_more_memory():
  def _set_memory_spec(container_op):
    container_op.set_memory_request('32G')
  return _set_memory_spec

# Then use this opfunc in KubeflowDagRunner
pipeline_op_funcs = kubeflow_dag_runner.get_default_pipeline_operator_funcs()
pipeline_op_funcs.append(request_more_memory())
config = KubeflowDagRunnerConfig(
    pipeline_operator_funcs=pipeline_op_funcs,
    ...
)
kubeflow_dag_runner.KubeflowDagRunner(config=config).run(pipeline)

Similar resource configuration functions include:

• set_memory_limit
• set_cpu_request
• set_cpu_limit
• set_gpu_limit

Try BigQueryExampleGen

BigQuery is a serverless, highly scalable, and cost-effective cloud data warehouse. BigQuery can be used as a source for training examples in TFX. In this step, we will add BigQueryExampleGen to the pipeline.

In Jupyter lab file editor:

Double-click to open pipeline.py. Comment out CsvExampleGen and uncomment the line which creates an instance of BigQueryExampleGen. You also need to uncomment the query argument of the create_pipeline function.

We need to specify which GCP project to use for BigQuery, and this is done by setting --project in beam_pipeline_args when creating a pipeline.

Double-click to open configs.py. Uncomment the definition of BIG_QUERY_WITH_DIRECT_RUNNER_BEAM_PIPELINE_ARGS and BIG_QUERY_QUERY. You should replace the project id and the region value in this file with the correct values for your GCP project.Note: You MUST set your GCP project ID and region in the configs.py file before proceeding.**

Change directory one level up. Click the name of the directory above the file list. The name of the directory is the name of the pipeline which is my_pipeline if you didn’t change the pipeline name.

Double-click to open kubeflow_runner.py. Uncomment two arguments, query and beam_pipeline_args, for the create_pipeline function.

Now the pipeline is ready to use BigQuery as an example source. Update the pipeline as before and create a new execution run as we did in step 5 and 6.

Update the pipeline and re-run it

# Update the pipeline
!tfx pipeline update \
  --pipeline-path=kubeflow_runner.py \
  --endpoint={ENDPOINT}

!tfx run create --pipeline-name {PIPELINE_NAME} --endpoint={ENDPOINT}

Try Dataflow

Several TFX Components use Apache Beam to implement data-parallel pipelines, and it means that you can distribute data processing workloads using Google Cloud Dataflow. In this step, we will set the Kubeflow orchestrator to use Dataflow as the data processing back-end for Apache Beam.Note: If the Dataflow API is not already enabled, you can enable it using the console, or from the CLI using this command (for example, in the Cloud Shell):

# Select your project:
gcloud config set project YOUR_PROJECT_ID

# Get a list of services that you can enable in your project:
gcloud services list --available | grep Dataflow

# If you don't see dataflow.googleapis.com listed, that means you haven't been
# granted access to enable the Dataflow API.  See your account adminstrator.

# Enable the Dataflow service:

gcloud services enable dataflow.googleapis.com

Note: Execution speed may be limited by default Google Compute Engine (GCE) quota. We recommend setting a sufficient quota for approximately 250 Dataflow VMs: 250 CPUs, 250 IP Addresses, and 62500 GB of Persistent Disk. For more details, please see the GCE Quota and Dataflow Quota documentation. If you are blocked by IP Address quota, using a bigger worker_type will reduce the number of needed IPs.

Double-click pipeline to change directory, and double-click to open configs.py. Uncomment the definition of GOOGLE_CLOUD_REGION, and DATAFLOW_BEAM_PIPELINE_ARGS.

Change directory one level up. Click the name of the directory above the file list. The name of the directory is the name of the pipeline which is my_pipeline if you didn’t change.

Double-click to open kubeflow_runner.py. Uncomment beam_pipeline_args. (Also make sure to comment out current beam_pipeline_args that you added in Step 7.)

Update the pipeline and re-run it

# Update the pipeline
!tfx pipeline update \
  --pipeline-path=kubeflow_runner.py \
  --endpoint={ENDPOINT}

!tfx run create --pipeline-name {PIPELINE_NAME} --endpoint={ENDPOINT}

You can find your Dataflow jobs in Dataflow in Cloud Console.

Try Cloud AI Platform Training and Prediction with KFP

TFX interoperates with several managed GCP services, such as Cloud AI Platform for Training and Prediction. You can set your Trainer component to use Cloud AI Platform Training, a managed service for training ML models. Moreover, when your model is built and ready to be served, you can push your model to Cloud AI Platform Prediction for serving. In this step, we will set our Trainer and Pusher component to use Cloud AI Platform services.

Before editing files, you might first have to enable AI Platform Training & Prediction API.

Double-click pipeline to change directory, and double-click to open configs.py. Uncomment the definition of GOOGLE_CLOUD_REGION, GCP_AI_PLATFORM_TRAINING_ARGS and GCP_AI_PLATFORM_SERVING_ARGS. We will use our custom built container image to train a model in Cloud AI Platform Training, so we should set masterConfig.imageUri in GCP_AI_PLATFORM_TRAINING_ARGS to the same value as CUSTOM_TFX_IMAGE above.

Change directory one level up, and double-click to open kubeflow_runner.py. Uncomment ai_platform_training_args and ai_platform_serving_args.Note: If you receive a permissions error in the Training step, you may need to provide Storage Object Viewer permissions to the Cloud Machine Learning Engine (AI Platform Prediction & Training) service account. More information is available in the Container Registry documentation.

Update the pipeline and re-run it

# Update the pipeline
!tfx pipeline update \
  --pipeline-path=kubeflow_runner.py \
  --endpoint={ENDPOINT}

!tfx run create --pipeline-name {PIPELINE_NAME} --endpoint={ENDPOINT}

You can find your training jobs in Cloud AI Platform Jobs. If your pipeline completed successfully, you can find your model in Cloud AI Platform Models.

14. Use your own data

In this tutorial, you made a pipeline for a model using the Chicago Taxi dataset. Now try putting your own data into the pipeline. Your data can be stored anywhere the pipeline can access it, including Google Cloud Storage, BigQuery, or CSV files.

You need to modify the pipeline definition to accommodate your data.

If your data is stored in files

1. Modify DATA_PATH in kubeflow_runner.py, indicating the location.

If your data is stored in BigQuery

1. Modify BIG_QUERY_QUERY in configs.py to your query statement.
2. Add features in models/features.py.
3. Modify models/preprocessing.py to transform input data for training.
4. Modify models/keras/model.py and models/keras/constants.py to describe your ML model.

You need to login in order to like this post: click here
